Profilitec LEVELTEC 3mm Cross Spacer for LEVELTEC System

Profilitec LEVELTEC 3mm Cross Spacer for LEVELTEC System

Cross tie-base is recommended to optimize the consumption, especially for small tiles

Features

• Cross tie-base for joints 3mm (1/8")
• The leveler does not require pliers or unscrew-drivers
• Easy positioning without screwing
• Automatic ejection of the thread
• 50% time saving compared to other systems
• Easy leveling adjustment with few degrees of rotation
• No need for further side action on the tiles, only a proper vertical pressure

How to Use Profilitec Tile Leveling System

• STEP 1: Place the tie-base below the floor or wall covering. Due to its reduced thickness and compact base, it does not interfere with the glue and establishes a joint of 1, 2, or 3 millimeters (per the UNI 11493 standard).
• STEP 2: Without screwing, insert the cap vertically until it hits the tile. With just one click, the installation time can be significantly reduced while fitting automatically in the thread.
• STEP 3: You can acquire the ideal alignment of the surface by rotating the tiles a few degrees to level them.
• STEP 4: Remove the LEVELTEC and work on the cap when the glue is fully dry. Take care to move in the joint's direction. The bottom of the threaded stick breaks, leaving nothing behind.
• STEP 5: Push down on the last thread to loosen the cap, allowing the thread to exit without unscrewing. The cap can be used again for further applications.
